A ductile iron check valve is a self-acting, one-way valve that allows fluid to flow in a single direction and closes automatically when the flow reverses, preventing backflow that could damage pumps, contaminate media, or flood upstream equipment. Unlike gate or globe valves, it has no handwheel or actuator: the disc is moved entirely by the flow itself. Our swing check valves are sand cast in ductile iron to ASTM A536, with typical pressure ratings of 125/200/250 PSI WOG and nominal sizes from 2" to 24", making them a workhorse component in water supply networks, HVAC circulation loops, oil transfer lines, and gas distribution systems.
The core benefit of the swing design is its full-port flow path: the disc swings fully clear of the bore, so turbulence and pressure drop stay low even at high flow rates. At our casting facility, body and bonnet are sand cast in ductile iron, then machined, fitted with an NBR or EPDM seat, and pressure-tested before shipment. We supply flanged and threaded connections and routinely customize face-to-face dimensions, seat materials, and coatings to match customer drawings.
| Item | Specification |
|---|---|
| Body / Bonnet Material | Ductile iron ASTM A536 (65-45-12) |
| Seat Material | NBR or EPDM (stainless steel seat available on request) |
| Disc Material | Ductile iron with NBR/EPDM facing, or stainless steel |
| Pressure Class | 125 / 200 / 250 PSI WOG (typical) |
| Nominal Size | 2" – 24" (DN50 – DN600, typical) |
| Connection | Threaded (NPT/BSP) or flanged (ANSI/EN per drawing) |
| Applicable Media | Water, oil, gas |
| Cracking Pressure | Typically 0.02 – 0.05 bar depending on size and orientation |
| Temperature Range | -10°C to +120°C with NBR/EPDM seat (typical) |
| Casting Process | Sand casting (green sand / resin sand), fully machined |
| Surface Coating | Fusion-bonded epoxy or nitride/anti-rust paint per requirement |
Typical values for reference only — final parameters to be confirmed against customer drawings.
The swing check valve uses a hinged disc on a pivot pin inside the body. Forward flow swings the disc clear of the seat, creating an unobstructed bore. When flow slows or reverses, gravity and back-pressure swing the disc back onto the seat, and line pressure presses it closed for a tight seal. Because the disc travels only a short 90° arc, opening requires a small forward differential — a low cracking pressure — so the valve responds gently to flow changes. It operates with no external power and minimal maintenance: the only moving parts are the disc, hinge, and pin. Horizontal lines and upward vertical flow are standard; we can advise on the correct orientation for your piping layout.
As a casting factory, we control the process from pattern to packaging. Options include non-standard face-to-face lengths, flange drilling to ANSI, EN, JIS, or AS standards, alternative seat materials (EPDM for hot water, NBR for oil, stainless steel for abrasive media), lever-and-weight or spring-assisted closures, and special coatings for buried or marine service. We develop new tooling from your drawings or samples: first articles are submitted with dimensional and material reports for approval before batch casting. Sample lead time is typically 2–4 weeks depending on tooling. ODM and OEM projects are welcome, and drawings remain confidential.
Every batch passes a documented inspection workflow: shell and body castings are checked for graphite nodularity and wall integrity before machining; finished valves undergo shell hydrostatic pressure testing and seat leakage testing with reference to API 598 / MSS SP practice at agreed acceptance criteria. Dimensional inspection covers face-to-face length, flange drilling, and bore alignment. Material certificates (chemical composition and mechanical properties per ASTM A536) accompany each shipment on request. Valves are packed in anti-rust bags with end protectors, in export-grade plywood cases; palletization and customer-specific labeling are available.
1. What is cracking pressure, and why does it matter?
Cracking pressure is the minimum upstream pressure needed to open the valve disc. If it is too high, the pump wastes energy and flow is restricted; if too low, the disc may flutter in low-flow systems. Swing check valves typically have low cracking pressure, which suits high-flow water and oil lines. Confirm the value against your system's minimum flow condition.
2. Should I choose a swing check valve or a dual disc (wafer) check valve?
Swing check valves offer a full-port path and very low pressure drop, ideal for larger pipes, wastewater, and lines with infrequent flow reversal. Dual disc wafer check valves are lighter, shorter face-to-face, and close faster — better for compact installations and pump-discharge protection. See our Dual Disc Check Valve for the compact alternative.
3. Can you match our existing valve dimensions for replacement projects?
Yes. Send us the drawing, sample, or measured face-to-face length and flange standard. Because we cast in-house, we can adapt the pattern and machining to match legacy installations, including non-standard flange drilling and coating systems.
