Custom Iron Casting Parts Machined to Your Drawing

Zhaoyuqi Machinery is an OEM iron casting foundry in Qingdao, China that manufactures custom iron casting parts to buyer drawings. For more than 20 years we have supplied grey iron and ductile iron components as a one-stop solution — from pattern and sample through bulk sand casting, machining and export packing — so buyers get a finished, inspected part rather than a raw casting.

What We Cast, and the Industries It Goes Into

The parts we pour are the iron components that hold machines together and put weight where a design needs it: housings, brackets, flanges, gear blanks, valve bodies, pump parts, machine bases, counterweights and structural supports. None of them come from a catalogue. Each starts as your drawing, your material specification and your annual volume, and the casting is built around those three rather than around the patterns we happen to have on the shelf.

In practice the work clusters by industry. Pump and valve housings for fluid equipment need pressure tightness and machined sealing faces. Gear blanks and transmission parts need consistent section and clean bores. Machine bases and frames are bought for stiffness and damping, not tensile strength. Counterweights are usually the cheapest iron per kilo a customer can buy, and we quote them that way. Brake supports and chassis brackets for vehicles are the opposite, fatigue-loaded, so they go in ductile iron. Custom structural brackets for construction round out the mix.

Iron Grade, and the Processing That Follows the Casting

Grey iron and ductile iron fail differently, and that difference decides the grade. Grey iron breaks before it bends, so it belongs where stiffness, damping and wear resistance dominate: machine bases, gear cases, counterweights, housings that never see impact. Ductile iron, with a spheroidization rate of at least 90%, yields and stretches before it fails, which makes it the safer choice for loaded brackets, gear blanks and anything holding pressure. If a drawing says only "cast iron", send the load case and we will propose a grade with the cost difference stated, rather than quietly pouring the cheaper one.

Moulding runs on a fully automatic clay sand line with furnace charge made from mill-direct pig iron, so chemistry is known before the first heat instead of being corrected after it. Castings leave the shake-out and go straight into finishing under the same roof: shot blasting and polishing for surface cleanliness, tapping, drilling and CNC machining for bores, faces and threads, then painting where the part will see weather or corrosion. Keeping those steps in one plant is what shortens the supply chain, because there is no second supplier to chase when a bore comes out undersized.

From RFQ to Crated Part: How the OEM Route Runs

The route is deliberately short. An RFQ is reviewed for castability, wall thickness and draft angle, and the reply carries a fixed unit price, tooling cost and sample lead time in one message. The first cast part is measured and submitted with material test data. Bulk then repeats the locked pattern and recipe batch by batch, and finished castings are inspected 100% dimensionally and visually before crating.

What makes that run smoothly is the inquiry itself. A complete one carries the drawing in PDF or STEP, the required standard such as ASTM or GB, trial and annual quantities, any heat treatment or coating requirement, and packaging preferences for export. With those five, a firm price comes back in one or two working days; without them every gap becomes a question, and questions are where schedules slip. On size, the short version is that the automatic line covers 0.5 to 50 kg and the lost foam line takes 50 to 200 kg.

The Weight and Wall Boundaries That Decide Your Route

Most custom iron parts land inside the same envelope: 0.5 to 50 kg per piece on our automatic clay sand line, with wall thickness from about 6 mm upward. Inside that envelope, pricing is stable and lead times are predictable. Things get interesting at the edges, and it is better to know before you finalize the drawing:

• Walls below 6 mm: castable, but the thinner the wall, the more the quote depends on section uniformity. A 5 mm wall next to a 15 mm boss causes more scrap than the thin wall itself.

• Pieces above 50 kg: they move to our lost foam line, which handles up to 200 kg (heavier by arrangement). Same drawings, different route, slightly different surface character.

• Very small parts under 0.5 kg: often better suited to shell molding, where finer sand gives cleaner detail on small hardware.

Send the drawing even if it sits outside these lines. Half of the unusual parts we quote get a route suggestion the customer had not considered, and several of those became our longest-running items.

Four Drawing Details That Quietly Raise Casting Cost

After twenty years of reviewing buyer drawings, the same details show up again and again as cost drivers. Sharp internal corners concentrate stress and crack molds — a radius costs nothing at design time. Uneven wall sections cool at different rates and pull the casting out of tolerance. Holes placed too close to a wall force tooling compromises. And machined surfaces called out everywhere "just in case" multiply the operations you pay for. Fix these four on paper and most quotes drop before a single mold is made.

The Cost Structure Behind an Iron Casting Quote

Buyers comparing quotes often compare only the unit price, which hides why two foundries differ by 30%. An iron casting price is roughly: metal cost by weight, molding cost by mold count, cleaning and fettling labor, machining if specified, coating if specified, and inspection scope. Metal cost tracks the market and moves — a quote that ignores pig iron movement will be renegotiated. Molding cost per piece falls as batch size rises, because setup spreads across more pieces.

So when quotes differ widely on the same drawing, the usual reasons are batch assumptions, machining scope, and inspection level — not the hourly rate. Ask each supplier to state batch size, machining scope and inspection in the quote. Ours does, and that is also why we ask for annual volume rather than first-order quantity: the price you see should be the price you get for the volume you actually buy.

What Happens When a First Article Fails

Occasionally the first casting does not meet the drawing. The useful question is not whether it happens — with new tooling it sometimes does — but how the supplier handles it. Ours is a short loop: measure the sample against the drawing, identify whether the deviation comes from pattern dimension, shrinkage allowance, or mold-related movement, correct the pattern, and re-cast. You get the measurement report and the correction made, not a request to relax the tolerance.

Two scenarios are worth naming because they need your input rather than ours. If the deviation is in a machined feature, we can often recover it by adjusting the machining allowance. If the deviation is in an as-cast surface that matters functionally, the drawing may need a small change — and we would rather propose that openly than ship parts that will be argued about at incoming inspection.

Frequently Asked Questions

Grey iron or ductile iron — how do I decide quickly?

If the part sees shock, bending loads or clamping forces, ductile iron. If it is a housing, base or cover where vibration damping and cost matter more, grey iron. Our page on gray iron castings covers the grey side in detail.

Can I get castings without any machining at all?

Yes, plenty of parts ship as-cast and shot blasted. Machining only pays for itself on fits and seals, so we machine the faces and bores that matter and leave the rest as-cast.

What does the first article include?

A sample casting with a dimensional report against your drawing, plus material certificates for the heat it came from. You approve the piece; bulk production runs on the same pattern with parameters locked.

How is tooling cost handled on repeat orders?

The pattern is built once and maintained by us for the life of the part. Repeat releases carry no tooling charge — one reason buyers consolidate long-running hardware with one foundry.

Do you cast parts that need pressure tightness?

Yes, with the caveat that tightness is a design outcome as much as a process one: section feeding, wall uniformity and where the machined surfaces sit all affect it. Tell us the test pressure at inquiry so the route is planned for it.

Can you copy a part from a physical sample?

Yes. We measure the sample, produce a drawing for your approval, and cast from that. It is common for legacy parts where the original drawing no longer exists.

Why Work With Zhaoyuqi

Every iron casting part we deliver goes through 100% inspection before packing — dimensions, surface and spheroidization all verified against your drawing. This is drawing-based OEM production from sample approval to bulk sand casting, supported by a 10,000 t/y annual output and a regular 30-day lead time. For a quotation, attach your drawing in the quote form.

Request a Quote

Send your drawing and quantity — we quote, build a sample for your approval, then move to bulk production.
