A gate valve body is a pressure vessel with a hole through it. Everything about the casting follows from that: the wall has to hold the pressure, the seat has to seal against a moving wedge, and the bonnet joint has to stay tight through a few thousand operating cycles.
The body contains the line pressure, and the pressure acts on the whole internal surface. On a DN200 PN16 valve, that is a force of about 50 kN trying to separate the body from the bonnet, plus the hoop stress in the wall around the bore.
Wall thickness is calculated from the diameter, the pressure and the material, with a corrosion allowance. Ductile iron at 450 MPa gives a thinner wall than grey iron at 250 MPa for the same rating, which is why ductile dominates above PN10.
The calculation is straightforward. What is not straightforward is getting a wall of that thickness cast without shrinkage porosity where the wall meets a flange or a boss, and that is the foundry's real job.
The seat is the machined face the wedge slides against. It has to be flat, square to the bore and hard enough not to groove.
On a resilient seated valve, the seat is a rubber or elastomer ring that the wedge compresses. The casting's job is to hold that ring in a groove of the right depth and profile, and to present a surface that does not cut it.
On a metal seated valve, the seat is a machined face on the body, often hardfaced. The casting has to be sound at that face, because porosity under a seat is a leak path that no amount of machining will close.
We machine the seat in the same setup as the bore, so the two are concentric within 0.05 mm. A seat that is 0.1 mm off-axis will leak on one side no matter how well the wedge is made.
The bonnet joint is a flange with a gasket, and it is the most common leak point on a gate valve. The flange has to be thick enough not to dish under bolt load, and the wall behind it has to be thick enough to resist the bending that the bolts impose.
Ribs help. A pair of ribs running from the bonnet flange down the body reduces the flange deflection and lets the wall stay thinner elsewhere. The ribs also feed the flange during solidification, which is where the shrinkage would otherwise appear.
On large valves, the body and bonnet are sometimes cast as one piece with a welded or bolted bonnet connection made at the factory. That removes the gasketed joint, and it makes the casting a single pressure boundary with no joint to leak.
The gate slides in guide slots cast into the body. Those slots keep the gate square to the seat, and if they are not parallel, the gate cocks and the valve leaks or jams.
The slots are cast and then, on larger valves, machined. The parallelism between the two slots is held to about 0.1 mm over the gate travel, because a gate that tilts by 0.1 mm over a 200 mm face opens a gap at the seat.
The stem passes through the bonnet and is guided by a bushing. The bonnet bore and the body seat have to be coaxial, which means the two castings have to be machined from a common datum, not independently. That is a fixture decision made at order, and it is worth asking about before approving a sample.
Three defects in a valve body are invisible until the body is pressurised.
Shrinkage porosity at the junction of the wall and the flange. The thick flange freezes last and pulls metal from the thinner wall, leaving a cavity behind the machined face.
Gas porosity from mould or core gas, usually as small round holes just under the surface on the bore.
Cold shuts on the bore, where two metal fronts met without fusing. They look like a line and behave like a crack under pressure.
The hydrostatic test finds all three, which is why every valve body we make is tested rather than sampled. A body that weeps at 1.5 times rated pressure is scrapped, not repaired.
The order of machining decides whether the valve works. The bore and the seat define the flow path and the seal; the flanges define how it bolts into the line.
If the flanges are machined first and the bore is located from them, the bore inherits the flange position, and the seat ends up off-axis if the two flanges are not perfectly aligned. If the bore is machined first and the flanges are faced from the bore, the seat is correct and the flange faces are square to the flow.
That matters because a valve bolted between two pipes with misaligned flanges puts a bending load on the body. The body should be the reference, not the pipe.
Potable water valves are lined with epoxy at 250 to 400 micrometres. The lining has to cover the waterway completely and must not intrude into the seat or the guide slots.
Masking is the practical answer. The seat faces, the guide slots and the stem bore are masked before coating, and the coating thickness at the edges of the mask is checked because a feathered edge will flake.
On a metal seated valve, the coating stops short of the seat and the seat is left bare, which is correct: a coating on a metal seat would be worn away by the first few operations anyway.
We spark test the lining on potable water valves. A pinhole in a lining is a corrosion cell and, eventually, a leak.
Every body is hydrostatically tested at 1.5 times the rated pressure, held for the standard's duration, with the shell test on the body and a seat test on the closed valve.
The body is marked with the size, the pressure rating, the material and the heat number, cast in or stamped before coating. A valve that cannot be identified in a pit is a valve nobody can maintain.
The documentation is a heat certificate, a pressure test record and a dimensional report on the critical features: bore, seat, flange drilling and face-to-face. For a utility, that package is usually as important as the valve.
A gate valve is opened and closed by turning a stem, and the torque required changes through the travel.
At the start, the torque is breakaway torque, which is higher because the seat is loaded and the stem packing has taken a set. Through the travel, the torque is friction in the stem thread and the packing. At the end, the torque rises sharply as the gate seats.
The actuator is sized on the maximum of those, with a margin. A valve that is hand-operated has a large margin by default, because a person can apply more torque than the valve needs. A motor-operated valve has a small margin, and a valve that needs 10 percent more torque than the actuator can give will stall at the seat.
The casting affects this through the guide slots and the seat alignment. A gate that is 0.1 mm out of square needs more torque to seat, and that extra torque is what stalls an actuator sized to the catalogue figure.
We cast the wedge on request. The stem is usually bar stock, and we machine it if the customer supplies the material.
Up to PN40 on the sizes we cast. Above that the wall thickness moves outside our range.
Not as a casting. A welded bonnet is a fabrication step, and we would supply the body and bonnet separately for the valve maker to join.
Epoxy at 250 to 400 micrometres, spark tested. Cement lining is not practical in a valve body of this complexity.
Both are machined in one setup from a common datum, and the concentricity is checked on the first article and sampled afterwards.
Five to six weeks for a repeat pattern including machining and testing, seven to nine for a new one.
